EX260 Fieldbus System

EX260 compact fieldbus system is a cost-effective communication solution designed for efficient output control in industrial automation. With serial communication, it reduces wiring complexity and installation time while maintaining a compact design.

Technical Specifications

• Model: EX260
• Type: Compact Fieldbus System (Output)
• Communication Type: Serial Communication
• Compatible Protocols: PROFIsafe, Ethernet POWERLINK, PROFINET, EtherNet/IP, EtherCAT, PROFIBUS DP, Safety over EtherCAT, DeviceNet, CC-Link, CC-Link IE TSN, IO-Link, Modbus, AS-Interface
• Maximum Solenoids: Up to 32
• Maximum Stations: Up to 24
• Compatible Valve Series: SY, JSY, VQC, S0700, SV
• Safety Features: PROFIsafe / Functional Safety over EtherCAT
• Environmental Option: ATEX Available
• Protection Rating: Up to IP67
